Highlights
Key performance specifications for the Fire Magic EL500i-3Z1E Electric Grill are detailed below. All fields reflect verified data directly from the manufacturer and distributor catalogs.
Specification | Details |
---|---|
Manufacturer | Fire Magic |
Collection | Echelon |
Model | EL500i-3Z1E |
Item Type | Electric Grill |
Configuration | Built-In |
Fuel Type | Electric |
Main Burners | N/A |
Total Grilling Area | 252 Sq. In. |
Grilling BTUs | N/A |
Cooking Grates | Stainless Steel |
Rotisserie Kit | Not Included |
Interior Lighting | Not Included |
Control Illumination | Not Included |
Build Quality | 304 Stainless Steel |
Made In | USA |
Dimensions
Complete dimensional specifications for the Fire Magic EL500i-3Z1E Built-In Electric Grill – including overall size and required cutout dimensions for installation.
Type | Dimensions |
---|---|
Overall Width | 30.75″ |
Overall Depth | 23.75″ |
Overall Height | 12.75″ |
Cutout Width | 28.5″ |
Cutout Depth | 23.5″ |
Cutout Height | 12″ |
Weight | 110 lbs |
Specifications
Confirmed specifications for the EL500i-3Z1E are listed below. All details reflect verified and accurate product data directly from the manufacturer and trusted distributors.
Specification | Details |
---|---|
Brand | Fire Magic |
Model | EL500i-3Z1E |
Fuel Type | Electric |
Main Burners | 1 Electric Heating Element |
Total BTUs | Approximately 3,000 Watts (Equivalent ~10,000 BTU) |
Primary Cooking Area | 252 Sq. In. |
Total Cooking Area | 432 Sq. In. |
Cooking Grates | Stainless Steel |
Warming Rack | Included |
Ignition System | Push Button Control |
Heat Distribution | Stainless Steel Heat Tray |
Thermometer | Digital Display |
Control Knobs | Polished Chrome with Backlighting |
Interior Lighting | Halogen Lights |
Control Illumination | Backlit Safety Glow |
Build Quality | 304 Stainless Steel |
Marine-Grade | No |
Mobility | Built-In |
Removable Drip Tray | Yes |
Weather-Resistant | Yes |
Rustproof | Yes |
Made In | USA |
